Specification | Unit | Capacity |
Product Capacity | ml | 1000 to 10000 |
Neck Dia | mm | 25 to 120 |
Max. Product Dia | mm | 190 |
Max. Product Height | mm | 450 |
Production Capacity (Vol-5Ltr, 46mm Neck) | Jar/Hr. | 360 to 400 |
Prodn Capacity (Vol-10ltr-46mm Neck) | Jar/Hr. | 180 to 200 |
No. of Preform Holders | no | 76 |
Cavity | no | 1 - 96 to 120mm |
Operating Pressure | kg | 8 to 9 |
Blowing Pressure | kg | 16 to 20 |
Heater Power | kw | 20 |
Running Power Consumption | kw | 7 to 8 |
Clamping Stroke | mm | 300 |
Mould Platen Size | mm | 550X500X38 |
Dist. Between Tie Bar | mm | 420 |
Cavity Centre Distance | mm | 170 |
Clamping Force | ton | 15 |
Max. Mould Thickness | mm | 360 |
Min. Mould Thickness | mm | 180 |
Air Requirement | kg/cfm | 25 / 50 |
Dimension of Main Blower-LWH | mm | 2500x610x1829mm |
Dimension of Preheater-LWH | mm | 2133x914x1829mm |
Weight of Main blower | kg | 885 |
Weight of Preheater | kg | 425 |
“ In our endeavor to improve quality, product specifications and look may change without prior notice”
