Specification | Unit | J20-ME |
Product Capacity | ml | 5000 to 20000 |
Neck Dia | mm | 46 to 130 |
Max. Product Dia | mm | 270 |
Max. Product Height | mm | 490 |
Production Capacity | Jars/Hr. | 75 to 80 |
Cavity | no | 1 |
Operating Pressure | Kg | 8 to 9 |
Blowing Pressure | Kg | 20 to 30 |
Heater Power | Kw | 32 |
Running Power Consumption | Kw | 17 to 18 |
Clamping Stroke | mm | 350 |
Mould Platten Size | mm | 600X550X50 |
Dist. Between Tie Bar | mm | 450 |
Cavity Centre Distance | - | - |
Clamping Force | ton | 15 |
Max.Mould Thickness | mm | 360 |
Min.Mould Thickness | mm | 350 |
Air Requirement | cfm | 60 to 80 |
“ In our endeavor to improve quality, product specifications and look may change without prior notice”
